MFZ518 with pre milling and Slotting woodworking automatic edge banding machine Apply to MDF, Block Board, Solid Wood Bo
Basic Info.
Model NO. MFZ450DJ
Automatic Grade Automatic
Panel Feeding Speed 20m/min
Certification CE, ISO, FDA
Panel Thinkness 10-60mm
Min.length panel 160mm
Min.width panel 60mm
Manufacturing Principles Glue Tank Underneath
Customized Customized
Warranty Time Offer Free Spare Parts and Service Within 12 Month
Working Experience Twenty Years′ Experience
Delivery Time 5-7 Days
Total Power 16.5kw
After-Sales Service Provided 24 Hours Technical Support by Email, Call, Video
Price Lowest Reasonable Offers with Best Machine
Voltage 380V/50Hz 3phase Can Be Customized
Air Pressure 0.7MPa
Machine Painting Color Be Made According to Your Need
Machine Item Automatic Woodworking Edge Banding Machine Wi
Transport Package Standard Package, Be Made According Cutomer Need
Specification 6585*970*1520mm
Trademark XINLIHUI Automatic Wood Edge Banding Machine
Origin Qingdao City
HS Code 84659100
Production Capacity 100/Week
Product Description

MFZ518 with pre milling and Slotting woodworking automatic edge banding machine Apply to MDF, Block Board, Solid Wood Board, Particleboard, Polymer Door Plates, Plywood Etc,Straight Line Edging And Trimming.Detail machine pictures, all photoes are for 100% real shooting ! For more pictures, video and details, please email me!1, Product Show2, Specification
Panel thickness10-60mm
Enging thickness0.4-3mm
Min.Width of panel≥80mm
Min. Length of panel≥160mm
Max.size of tape higher than panel(each side )2mm
Panel feeding speed≤20mm/min(variable speed)
Pneumatic power0.7Mpa
Power380V 3N/PE 50Hz Can be customzied
Panel feeding motor1.5KW
Glue axis motor0.75kw
Edge-cutting motor3kw*2 200Hz 12000r/min
Rough triming motor1.1kw*2 200Hz 12000r/min
Fine trimming motor0.5kw*2 200Hz 12000r/min
Buffing motor0.25kw*2 50Hz 2800r/min
Heating power of glue tank2.5KW
Secondary heating power0.12KW
Lnstalled power9.57KW
Total current19.13A
Glue temperature fo readging (reference)180-200ºC
Overall dimensions6585*970*1520mm

5, Features1:Flexible, advantages of high performance, easy debugging, convenient in maintenance and easy to operate.2: high quality electric components and transmitting component make machines fuction more steady.3: Full-close safety shield,more human,enduring.5.Stable performance.8, Company InformationQingdao Xinlihui Machinery Co., Ltd is one of the large-scale woodworking machinery manufacturer in China. The company is located in Wangtai town. Our company is a comprehensive enterprise which is specialized in research and development, design, manufacturing, sale and service. With advanced production equipment and professional technical staff of research and development, and management. Which is formed a unique management model and the standardization of production process. The leading products of woodworking products are CNC router, panel saw series, sanding machine series, woodworking drill machine, Pur wrapping machine, paper sticking machine, vacuum laminating machine, edge banding machine, computer engraving machine and the other series and over sixty standards. With the scientific management, unique technology, and innovative products to meet customer demands. Our products get a very high reputation from our customers at home and abroad. Our products are sold across the country and to Russia, Ukraine, Middle-East, South Africa, Southeast Asia, Central Europe and the other countries and areas. We have earned the trust of customers and our product process is in the leading level among the same industry of domestic. It creates a famous brand called "XINLIHUI" and our products sell well both at home and abroad. It is the most trusted brand to our customers. We would like to work a new win-win development with the insight colleagues and we welcome all the new and old friends to visit our company and crest a brilliant tomorrow together.
